Item description/product images

DescriptionMaterial:Housing plastic (ABS).
Magnetic core hard ferrite.Note:These magnets are often used on notice boards, whiteboards and magnetic boards.Temperature range:max. 100°C.On request:Magnetic core NdFeB (neodymium).Drawing reference:

1) Magnetic face
2) Magnet
3) Housing

Special features:

Drawings

Item selection/filter

Order No.	Colour	D	D1	H	H1	Magnetic force N	Price
K1398.101	white	10,5	9,5	7	1,5	0,7	on request
K1398.161	white	16	14,5	7	1,1	1,3	on request
K1398.201	white	20	16	7	2,1	1,5	on request
K1398.251	white	25	22	8	2,2	10	on request
K1398.301	white	30	28	8	2	14	on request
K1398.361	white	36	32,5	9	2,2	9,5	on request
K1398.102	blue	10,5	9,5	7	1,5	0,7	on request
K1398.162	blue	16	14,5	7	1,1	1,3	on request
K1398.202	blue	20	16	7	2,1	1,5	on request
K1398.252	blue	25	22	8	2,2	10	on request
K1398.302	blue	30	28	8	2	14	on request
K1398.362	blue	36	32,5	9	2,2	9,5	on request
K1398.103	red	10,5	9,5	7	1,5	0,7	on request
K1398.163	red	16	14,5	7	1,1	1,3	on request
K1398.203	red	20	16	7	2,1	1,5	on request
K1398.253	red	25	22	8	2,2	10	on request
K1398.303	red	30	28	8	2	14	on request
K1398.363	red	36	32,5	9	2,2	9,5	on request
K1398.104	black	10,5	9,5	7	1,5	0,7	on request
K1398.164	black	16	14,5	7	1,1	1,3	on request
K1398.204	black	20	16	7	2,1	1,5	on request
K1398.254	black	25	22	8	2,2	10	on request
K1398.304	black	30	28	8	2	14	on request
K1398.364	black	36	32,5	9	2,2	9,5	on request
