K0788 AG metricCam Levers with external thread, steel; metric |
go back |
|
Item description/product images |
|
|
DescriptionMaterial:Handle steel 1.0401.
Thrust washer plastic PA 66 GF 35-X fiberglass reinforced.
Hinge pin stainless steel 1.4305 (AISI 303 equivalent).
Stud and washer steel, quality class 5.8.Version:Handle, stud and washer trivalent blue passivated.
Thrust washer black.
Hinge pin bright.Note:Plastics are subject to creeping when compressed (retardation).
For the inch series, dimension D is in inches, all other dimensions are in mm.Special features: DownloadHere is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table.
|
| Item No. | Size | D | D1 | D2 | B | B1 | H | H1 | A | A1 | L | Clamping
force
F (kN) | Hand
force
FH N | Stroke
S | CAD | Acc. | Price | Order |
|---|
| K0788.1502205X20 | 1 | M5 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 20 | 4 | 120 | 1,2 |  | | 15.02 $ (USD) | | | K0788.1502205X30 | 1 | M5 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 30 | 4 | 120 | 1,2 | | | 15.02 $ (USD) | | | K0788.1502205X40 | 1 | M5 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 40 | 4 | 120 | 1,2 | | | 15.38 $ (USD) | | | K0788.1502205X50 | 1 | M5 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 50 | 4 | 120 | 1,2 | | | 15.38 $ (USD) | | | K0788.1502206X20 | 1 | M6 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 20 | 4 | 120 | 1,2 | | | 15.02 $ (USD) | | | K0788.1502206X30 | 1 | M6 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 30 | 4 | 120 | 1,2 | | | 15.02 $ (USD) | | | K0788.1502206X40 | 1 | M6 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 40 | 4 | 120 | 1,2 | | | 15.38 $ (USD) | | | K0788.1502206X50 | 1 | M6 | 18,1 | 9 | 21,5 | 15 | 14,5 | 22 | 70,4 | 79,2 | 50 | 4 | 120 | 1,2 | | | 15.38 $ (USD) | | | K0788.2502208X25 | 2 | M8 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 25 | 8 | 350 | 1,5 | | | 24.61 $ (USD) | | | K0788.2502208X30 | 2 | M8 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 30 | 8 | 350 | 1,5 | | | 24.61 $ (USD) | | | K0788.2502208X40 | 2 | M8 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 40 | 8 | 350 | 1,5 | | | 26.33 $ (USD) | | | K0788.2502208X50 | 2 | M8 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 50 | 8 | 350 | 1,5 | | | 26.33 $ (USD) | | | K0788.2502210X25 | 2 | M10 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 25 | 8 | 350 | 1,5 | | | 24.61 $ (USD) | | | K0788.2502210X30 | 2 | M10 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 30 | 8 | 350 | 1,5 | | | 24.61 $ (USD) | | | K0788.2502210X40 | 2 | M10 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 40 | 8 | 350 | 1,5 | | | 26.33 $ (USD) | | | K0788.2502210X50 | 2 | M10 | 27,1 | 11 | 33,2 | 24 | 18 | 28,5 | 96 | 108 | 50 | 8 | 350 | 1,5 | | | 26.33 $ (USD) | |
