Product groups
Self-aligning pads, self-righting, Form G, press fit, flattened ball, smooth
K1164_G

Self-aligning pads, self-righting, Form G, press fit, flattened...

go back

Item description/product images

DescriptionMaterial:Ball high-carbon steel, ball seat steel.Version:Ball phosphated, ball seat hardened.Note:The self-aligning pads serve as stops, rests and thrust pads in fixture construction.
The seating face returns to the start position when the load is removed.

Ball secured against rotation.
Special features:
RoHS

Drawings

Self-aligning pads, self-righting, Form G, press fit, flattened ball, smooth

Item selection/filter

Order No.FormD1D2LETSW1SW2Ball ØLoad rating
max. kN
(static load only)
CADAcc.PriceOrder
K1164.403GM391311,5510698on request
K1164.404GM412181561381216on request
K1164.405GM5182521,9819101732on request
K1164.406GM6263631,21027162564on request
K1164.408GM8304034,61230172890on request
