{"product":{"productId":"agid.24228","price":1.78,"name":"Seal washers in Hygienic DESIGN"},"currency":"USD"}
Material
EU10/2011 and FDA constyle thermoplastic (POM).
Version
RAL5002 - Ultramarine blue (POM).
Show more
Show less
Description
Product description
The thermoplastic seal washer in Hygienic DESIGN was specially developed for use in combination with the hex head bolt K1647 or hex nut K1648. Special emphasis has been placed on the cleaning-optimized geometry and a surface finish of Ra ≤ 0.8 µm.
The seal washers are made from an EU10/2011 and FDA constyle plastic granulate.
The seal washers are made from an EU10/2011 and FDA constyle plastic granulate.
Material
EU10/2011 and FDA constyle thermoplastic (POM).
Version
RAL5002 - Ultramarine blue (POM).
Note
Sealing ring is unsuitable for acidic cleaning (pH < 4) and oxidizing agents.
Temperature range
-20 °C to +100 °C (POM).
Advantages
Foodstuff constyle material.
Cleaning optimized geometry.
Cleaning optimized geometry.
Attention
The suitability of the Hygienic DESIGN fasters for the respective application must be checked by the user. Depending on the loads and external influences (temperature, cleaning media, product media), the sealing washer should be inspected regularly and replaced if necessary.
Scope of delivery
Seal washer.
On request
Special versions.
Threaded version
M4 - M16.
Accessory
Stainless steel hex head bolt with seal washer K1647.
Stainless steel hex nut with seal washer K1648.
Stainless steel hex nut with seal washer K1648.
