Spring Plungers ball style, slotted, steel, standard end pressure, inch
 K0309 Inch

Spring Plungers ball style, slotted, steel, standard end...

 go back

Item description/product images
DescriptionMaterial:Sleeve steel grade 5.8.
Ball steel.
Spring grade D steel wire.Version:Black oxidised. Ball hardened.Note:For the inch series, dimension D is in inches, all other dimensions are in mm.

Drawings

Spring Plungers ball style, slotted, steel, standard end pressure, inch

Item selection/filter
Order No.

DD1LHNSpring force
initial pressure
F1 approx. N		Spring force
final pressure
F2 approx. N		CADAcc.PriceOrder
K0309.AD6-321,570,40,41,53 2.47 $ (USD)
K0309.AG8-362,590,80,6410 1.77 $ (USD)
K0309.AE8-322,590,80,6410 1.77 $ (USD)
K0309.A110-323120,90,8611 1.77 $ (USD)
K0309.AJ1/4-283,51411913 1.77 $ (USD)
K0309.A21/4-203,51411913 1.77 $ (USD)
K0309.A35/16-185161,51,21530 2.50 $ (USD)
K0309.A43/8-1661921,62040 2.62 $ (USD)
K0309.A51/2-138222,523055 4.02 $ (USD)
K0309.A65/8-1110243,52,565125 5.42 $ (USD)
