Knurled knobs

go back

Products
- Knobs
  - Knurled Knobs
    - Knurled knobs

Item description/product images

DescriptionMaterial:Thermoset PF 31, black.
Screw, steel.
Tapped bush, steel or brass.Version:Screw, electro zinc-plated.
Tapped bush, electro zinc-plated or bright brass.Drawing reference:

Form C: tapped blind hole
Form E: tapped bush
Form L: external thread

Special features:

Drawings (total overview)

Knurled knobs, Form C, with tapped blind hole

More information

Drawings

Knurled knobs, Form C, with tapped blind hole

Item selection/filter

Order No.	Form	Component material	D	D1	D2	H	H1	T	CAD	Acc.	Price	Order
K1223.102206	C	plastic	M6	22	12	13	6	7,5			on request
K1223.102606	C	plastic	M6	26	17	20	14	9			on request

Knurled knobs, Form E, with tapped bush

More information

Drawings

Item selection/filter

Order No.	Form	Component material	D	D1	D2	H	H1	T	Price
K1223.212205	E	brass	M5	22	12	13	6	6	on request
K1223.202606	E	steel	M6	26	17	20	14	10	on request
K1223.202608	E	steel	M8	26	17	20	14	12	on request

Knurled knobs, Form L, with external thread

More information

Drawings

Knurled knobs, Form L, with external thread

Item selection/filter

Order No.	Form	Component material	D	D1	D2	H	H1	L	Price
K1223.302205X10	L	steel	M5	22	12	13	6	10	on request
K1223.302205X15	L	steel	M5	22	12	13	6	15	on request
K1223.302205X20	L	steel	M5	22	12	13	6	20	on request
K1223.302206X10	L	steel	M6	22	12	13	6	10	on request
K1223.302206X15	L	steel	M6	22	12	13	6	15	on request
K1223.302206X20	L	steel	M6	22	12	13	6	20	on request
K1223.302206X30	L	steel	M6	22	12	13	6	30	on request
K1223.302606X10	L	steel	M6	26	15	13	6	10	on request
K1223.302606X15	L	steel	M6	26	15	13	6	15	on request
K1223.302606X20	L	steel	M6	26	15	13	6	20	on request
K1223.302606X30	L	steel	M6	26	15	13	6	30	on request
K1223.302608X15	L	steel	M8	26	15	13	6	15	on request
K1223.302608X20	L	steel	M8	26	15	13	6	20	on request
K1223.302608X30	L	steel	M8	26	15	13	6	30	on request
