Adjustable Latches screw-on holes covered Style A
K0047_SVA

Adjustable Latches screw-on holes covered Style A

go back

Item description/product images

DescriptionMaterial:Steel or stainless steel 1.4301.Version:Galvanised and blue passivated
Stainless steel bright.
Note:Adjustable latches are safe locking systems for industrial applications. By exceeding the dead centre they resist vibration.

After the hook is engaged with the catch plate, by pushing the lever down the parts to be locked can be drawn together by up to 5 mm.
To compensate for tolerances or to create enough tension, the hook length can be adjusted using the M5 threaded spindle.

The latches can be screwed down riveted.

Any catch plate can be combined with any latch.

Order required catch plate version separately.

The retaining force F1 applies to the latch, not the catch plate.
Drawing reference:
Form A standard

1) Hole arrangements for assembly with catch plate
Special features:
RoHS

Drawings

Adjustable Latches screw-on holes covered Style A

Overview of items (compressed)

Item selection/filter
Order No.
Steel
Order No.
Stainless steel
FormRetaining
force
F1 N
Filter
K0047.1420601K0047.1420602A1000
