Item description/product images

DescriptionMaterial:Housing, steel plate.
Wheel tread, high quality polyurethane elastomere.
Wheel rims, die-cast aluminium.Version:Housing, press-formed.
Swivel housing, double-row ball bearings in a swivel head.
Ball bearing wheel axle bearings.Note:Wheel axle bolted.
Swivel and fixed castors with mounting plate.Application:Heavy loads can be easily transported using this load handling equipment. The roll and swivel resistance is reduced with this new wheel series designed for intralogistic heavy load applications.Temperature range:-25 °C to +70 °C

Drawings

Item selection/filter

Order No.	Item	Wheel bearing	A	B	B1	B2	B3	D	D1	H	L	L1	L2	R	Permissible load kg	Price
K1765.101000402	Swivel castor	ball bearing	36	40	60	55	85	100	9	125	100	80	76	86	200	252.69 $ (USD)
K1765.101250402	Swivel castor	ball bearing	40	40	60	55	85	125	9	150	100	80	76	102,5	200	254.87 $ (USD)
K1765.101500502	Swivel castor	ball bearing	60	50	80	75	110	150	11	190	140	105	-	135	400	344.16 $ (USD)
K1765.101600502	Swivel castor	ball bearing	60	50	80	75	110	160	11	195	140	105	-	140	400	382.21 $ (USD)
K1765.102000502	Swivel castor	ball bearing	65	50	80	75	110	200	11	235	140	105	-	165	400	449.15 $ (USD)
