Item description/product images

DescriptionMaterial:Housing sheet steel,
Wheels high quality elastic solid rubber.
Wheel rim high-quality unbreakable polyamide (wheel Ø 100 and 125 mm) or die-cast aluminium (wheel Ø from 150 mm).Version:Housing, press-formed.
Swivel housing, double-row ball bearings in a swivel head.
Ball bearing wheel axle bearings.Note:Wheel axle bolted.
Swivel and fixed castors with mounting plate.Application:Maximum travel comfort, excellent cushioning of the transported goods. The new soft rubber series brings noticeable noise reduction in all applications.Temperature range:-25 °C to +80 °C.Special features:

Drawings

Item selection/filter

Order No.	Item	Wheel bearing	B	B1	B2	B3	D	D1	H	L	L1	L2	Permissible load kg	Price
K1766.101000401	Fixed castor	ball bearing	40	60	55	85	100	9	125	100	80	76	150	87.01 $ (USD)
K1766.101250401	Fixed castor	ball bearing	40	60	55	85	125	9	150	100	80	76	150	107.97 $ (USD)
K1766.101500401	Fixed castor	ball bearing	40	80	75	110	150	11	190	140	105	-	280	190.99 $ (USD)
K1766.101600501	Fixed castor	ball bearing	50	80	75	110	160	11	195	140	105	-	300	194.78 $ (USD)
K1766.102000501	Fixed castor	ball bearing	50	80	75	110	200	11	235	140	105	-	300	249.77 $ (USD)
