Product groups
Tension levers with reamed hole, 20°
K0176_PB20

Tension levers with reamed hole, 20°

go back

Item description/product images

DescriptionMaterial:Steel parts quality class 5.8.
Ball knob black plastic.
Version:Black oxide finish.Note:Tension levers can be used for simple clamping or control operations.
Where applicable, there must be enough space available so that the grip can be rotated 360°.
On request:Other internal threads, reamed holes and special versions.
Dimension “A” available in other lengths at extra charge.
Special features:
RoHS
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
 Datasheet K0176_PB Tension levers with reamed hole 143 kB
 Datasheet K0176_PB20 Tension levers with reamed hole, 20° 149 kB

Drawings

Tension levers with reamed hole, 20°

Item selection/filter

Item No.Fastening possibilityXTA=handle lengthA2DD1D2HH1H2CADAcc.PriceOrder
K0176.110reamed hole102284,5152410254052,532,5 13.99 $ (USD)
K0176.112reamed hole122510015281232466136,5 17.35 $ (USD)
K0176.114reamed hole142510015281232466136,5 17.35 $ (USD)
K0176.116reamed hole162812115331332527241 20.97 $ (USD)
K0176.120reamed hole203212315411332618049 29.07 $ (USD)
