Vent screws brass with check valve
K0461

Vent screws brass with check valve

go back

Item description/product images

DescriptionMaterial:Housing and cap brass.
Spring stainless steel.
Lift disc aluminium.
O-ring rubber (NBR).
Version:Flat seal asbestos-free.Note:Opening pressure 0.3 bar (±0.1).Functional principle:See K0459 vent screws with check valve.Drawing reference:
1) flat seal
2) O-ring
3) lift disc
4) vent hole 2x
5) cap
RoHS
DownloadHere is all the information as a PDF datasheet:
 Datasheet K0461 Vent screws brass with check valve 290 kB

Drawings

Vent screws brass with check valve

Item selection/filter

Item No.

DD1LL1SWCADAcc.PriceOrder
K0461.2001420G1/424,37,518on request
K0461.2403824,5G3/824,58,522on request
K0461.3001230G1/224,58,527on request
