Product groups
Lateral spring plungerswithout thrust pin
K0370

Lateral spring plungers without thrust pin

go back

Item description/product images

Show/filter all items
DescriptionMaterial:body aluminum.
Receiving washer steel.
Spring steel.
Version:Body blue galvanized.
Washer, hardened, black oxide finish.
Note:The thrust pin can be made to suit the required circumstances and screwed into the tapped hole in the locating washer.
The required lateral thrust (F) can be achieved through the stroke (S) and length (L).
style B has a seal to keep metal chips and dirt out.
RoHS
DownloadHere is all the information as a PDF datasheet:
 Datasheet K0370 Lateral spring plungerswithout thrust pin 156 kB

Drawings (total overview)

Lateral spring plungerswithout thrust pin

Lateral spring plungers without thrust pin, style A without seal

More information

Drawings

Lateral spring plungers without thrust pin, style A without seal

Item selection/filter

Item No.Style

DD1D2LL1SF
ca.N
CADAcc.PriceOrder
K0370.31054A10M4104121,620on request
K0370.31056A10M4104121,650on request
K0370.31058A10M4104121,6100on request
K0370.31064A10M4107,512240on request
K0370.31066A10M4107,512275on request
K0370.31068A10M4107,5122100on request
K0370.31104A16M61611,5183,2100on request
K0370.31106A16M61611,5183,2150on request
K0370.31108A16M61611,5183,2200on request

Lateral spring plungers without thrust pin, style B

More information

Drawings

Lateral spring plungers without thrust pin, style B

Item selection/filter

Item No.Style

DD1D2LL1SF
ca.N
CADAcc.PriceOrder
K0370.32054B10M4104121,620on request
K0370.32056B10M4104121,650on request
K0370.32058B10M4104121,6100on request
K0370.32064B10M4107,512240on request
K0370.32066B10M4107,512275on request
K0370.32068B10M4107,5122100on request
K0370.32104B16M61611,5183,2100on request
K0370.32106B16M61611,5183,2150on request
K0370.32108B16M61611,5183,2200on request
