Self-aligning pads with O-ring, style P, stainless steel insert with polythene face
K0284_P

Self-aligning pads with O-ring, style P, stainless steel insert...

go back

Item description/product images

DescriptionMaterial:Body carbon steel.
Ball stainless steel with polyurethane surface.
Version:Body tempered and black oxide finish.
Ball: polyurethane, hardness Shore 60.
Note:The self-aligning pads are used to support and clamp unmachined and machined workpieces.
In addition, they serve as stops, supports and pressure pieces in fixtures and toolmaking.

Ball secured against rotation.

style P: The polyurethane surface is permanently vulcanised on the ball. It is abrasion-resistant and does not discolor. Offers optimum protection against damage to delicate surfaces. The pearl-like surface gives a firm grip and allows air to escape so as to prevent any suction effect between the contact surface and the self-aligning pads.
Benefits:The built-in O-ring holds the ball in place and keeps dirt and foreign particles out ensuring smooth and even movement.
RoHS

Drawings

Self-aligning pads with O-ring, style P, stainless steel insert with polythene face

Item selection/filter

Item No.Style

D1D2D3LL1L3WBall ØCADAcc.PriceOrder
K0284.604X014P10M410---28-on request
K0284.604X027P10M410---28-on request
K0284.605X019P13M513---28-on request
K0284.605X028P13M513---28-on request
K0284.606X023P17M616---28-on request
K0284.608X026P19M821---24-on request
K0284.610X030P24M1023---24-on request
