Product groups
Levelling feet threaded spindles steel or stainless steel
K0427

Levelling feet threaded spindles steel or stainless steel

go back

Item description/product images

DescriptionMaterial:Steel or 1.4305 (AISI 303 equivalent) stainless steelVersion:Steel trivalent blue passivated.
Stainless steel, bright.
Order information:

If the threaded spindle and the levelling foot plate are to be supplied assembled, please add the suffix “assembled” to the order number for the spindle and plate. (e.g. K0427.120661 and K0423.1060 assembled.)

Note:Levelling feet consist of a plate and a threaded spindle. Any plate can be combined with any threaded spindle.
The height of the complete levelling foot is calculated from the length of the threaded spindle + 30 mm.
(Total height of levelling foot = L + 30 mm)
Special features:
RoHS
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
 Datasheet K0427 Levelling feet threaded spindles steel or stainless steel 184 kB

Drawings

Levelling feet threaded spindles steel or stainless steel

Item selection/filter

Item No.

Main
material
D1LSWLoad rating
max. kN
CADAcc.PriceOrder
K0427.120661steelM1266227,7 6.98 $ (USD)
K0427.121001steelM12100227,7 7.30 $ (USD)
K0427.121251steelM12125227,7 7.84 $ (USD)
K0427.121501steelM12150227,7 8.00 $ (USD)
K0427.160661steelM16662214,5 8.74 $ (USD)
K0427.161001steelM161002214,5 8.87 $ (USD)
K0427.161251steelM161252214,5 9.90 $ (USD)
K0427.161501steelM161502214,5 10.60 $ (USD)
K0427.162001steelM162002214,5 12.21 $ (USD)
K0427.201001steelM201002224,3 10.46 $ (USD)
K0427.201251steelM201252224,3 10.46 $ (USD)
K0427.201501steelM201502224,3 11.33 $ (USD)
K0427.202001steelM202002224,3 13.39 $ (USD)
K0427.120662stainless steelM1266227,7 12.21 $ (USD)
K0427.121002stainless steelM12100227,7 13.27 $ (USD)
K0427.121252stainless steelM12125227,7 14.52 $ (USD)
K0427.121502stainless steelM12150227,7 14.99 $ (USD)
K0427.160662stainless steelM16662214,5 15.27 $ (USD)
K0427.161002stainless steelM161002214,5 17.13 $ (USD)
K0427.161252stainless steelM161252214,5 19.31 $ (USD)
K0427.161502stainless steelM161502214,5 20.10 $ (USD)
K0427.162002stainless steelM162002214,5 23.87 $ (USD)
K0427.201002stainless steelM201002224,3 19.76 $ (USD)
K0427.201252stainless steelM201252224,3 22.06 $ (USD)
K0427.201502stainless steelM201502224,3 23.87 $ (USD)
K0427.202002stainless steelM202002224,3 27.67 $ (USD)
