Toggle clamps horizontal heavy-duty with adjustable clamping spindle
 K0077

Toggle clamps horizontal heavy-duty with adjustable clamping...

 go back

Item description/product images
DescriptionMaterial:Steel. Body and grip cast steel.Version:Trivalent passivated.
Clamping spindle and nuts phosphated.
Plastic grip oil-resistant.Accessory:K0100
K0101
K0102
K0103
K0106
K0107Special features:
RoHS
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
Datasheet K0077 Toggle clamps horizontal heavy-duty with adjustable clamping spindle 98,9 kB

Item selection/filter
Order No.Opening
angle of
holding arm		Opening
angle of
handle		Hand
force
FH N		Retaining
force
F1 N		Retaining
force
F2 N		Clamping
force
F3 N		Clamping
force
F4 N		CADAcc.PriceOrder
K0077.070090°95°2504500900018003550K0100.32 141.60 $ (USD)
