Adjustable Tension Levers low profile, external thread, 0°, inch

go back

Products
- Adjustable Handles
  - Adjustable Tension Levers
    - Adjustable Tension Levers low profile, external thread
      - Adjustable Tension Levers low profile, external thread, 0°, inch

Item description/product images

DescriptionMaterial:Steel parts grade 5.8.
Ball knob black plastic.Version:Black oxidized.On request:Other threads, screw lengths and special versions.
Dimensions “H1” and “A” available in other lengths at extra charge.Drawing reference:

1) flat point DIN EN ISO 4753

Special features:

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet K0114_0 Inch Adjustable Tension Levers low profile, external thread, 0°, inch

187 kB

Drawings

Overview of items (compressed)

Item selection/filter

Order No.	style	X	A=Handle length	D	D1	D2	D3	H	H1	H2	H3	L	No. of teeth
K0114.1A31X	0°	5/16-18	102	13,5	33	25	10	19	2	12	23	20/25/30/40/50/60	20
K0114.1A41X	0°	3/8-16	102	13,5	33	25	10	19	2	12	23	20/25/30/40/50/60	20
K0114.2A41X	0°	3/8-16	131	19	41	30	12	22	2	13,5	26	20/25/30/40/50/60	24
K0114.2A51X	0°	1/2-13	131	19	41	30	12	22	2	13,5	26	20/25/30/40/50/60	24
K0114.3A51X	0°	1/2-13	148	23	45	37	14	28	2	17	33	20/25/30/40/50/60	26
K0114.3A61X	0°	5/8-11	148	23	45	37	14	28	2	17	33	20/25/30/40/50/60	26
