Bushing for Ball Lock Pins

K0724

Bushing for Ball Lock Pins

Products
- Ball Lock Pins
  - Accessories
    - Bushing for Ball Lock Pins

Item description/product images

DescriptionMaterial:

Stainless steel 1.4305 (AISI 303 equivalent).

Version:Steel parts bright.Note:These bushings are ideal for easy and quick positioning of ball lock pins and locking pins.Benefits:- centered by the centering collar.
- easy and reliable installation.
- can be screwed into various materials.
- usable both sidesSpecial features:

Stainless steel

RoHS

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet K0724 Bushing for Ball Lock Pins

Drawings

Bushing for Ball Lock Pins

Item selection/filter

Item No.	D	D1	D2	D3	L	L3	L4	L5	SW	T	CAD	Acc.	Price	Order
K0724.10512	5	M12	6	9	25	4	7	3	5	4			16.89 $ (USD)
K0724.10616	6	M16	7,5	12	30	5	10	5	6	5			19.54 $ (USD)
K0724.10816	8	M16	10	12	30	5	10	5	8	5			19.54 $ (USD)
K0724.11024	10	M24	13	18	35	6	8	7	10	6			36.57 $ (USD)
K0724.11224	12	M24	15	18	35	6	8	7	12	6			36.57 $ (USD)
K0724.11630	16	M30	20	24	40	8	11	9	16	7			39.59 $ (USD)
