Indexing plungers are used where any change in locking position due to lateral forces should be prevented. A new indexed position can be only be moved to after the pin has been manually retracted.
Style B is recommended for applications where the indexing pin should remain disengaged for an extended period and be prevented from springing back.

The indexing plungers with bushings are a perfect combination for quick positioning and securing. The precise design of both the indexing plunger and the bushing guarantees high repeat accuracy when joining two elements.

Free-cutting steel.
Spherical knob thermoplastic.

Hardened and ground,
Spherical knob black-gray RAL7021.

Technical information see assembly and installation instructions.

Style A: standard version
Style B: lock-out version
