One-piece shaft collar, slitted inside
K0611

One-piece shaft collar, slitted inside

go back

Item description/product images

DescriptionMaterial:Steel.
Stainless steel 1.4305 (AISI 303 equivalent).
Stainless steel 1.4404 (AISI 316L equivalent).
Aluminum.
Version:Steel black oxidized, screw steel 12.9.
Stainless steel 1.4305 bright, screw stainless-steel A2-70.
Stainless steel 1.4404 bright, screw stainless steel A2-70.
Aluminum bright, screw stainless-steel A2-70.
Note:One-piece shaft collars with an inner slit surround the shaft with an equal distribution of the clamping force. This leads to a very precise fit and high retaining force without damaging the shaft.

The shaft tolerance should lie within h11.

The shaft collars made of A4 stainless steel have a small center point mark on the OD.
Temperature range:-40 °C - +175 °C.On request:Other dimensions.Special features:
RoHS
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
 Datasheet K0611 One-piece shaft collar, slitted inside 233 kB

Drawings

One-piece shaft collar, slitted inside

Item selection/filter

Order No.Style definitionMain
material
B

C
(DIN 912)
D1D2RCADAcc.PriceOrder
K0611.00401slitted insidesteel9M3x841620,7 4.74 $ (USD)
K0611.00501slitted insidesteel9M3x851620,7 4.74 $ (USD)
K0611.00601slitted insidesteel9M3x861620,7 4.74 $ (USD)
K0611.00801slitted insidesteel9M3x881822,4 4.74 $ (USD)
K0611.01001slitted insidesteel9M3x10102426 5.54 $ (USD)
K0611.01201slitted insidesteel11M4x12122831,8 6.14 $ (USD)
K0611.01501slitted insidesteel13M5x16153439,4 7.28 $ (USD)
K0611.01601slitted insidesteel13M5x16163439,4 7.28 $ (USD)
K0611.01801slitted insidesteel13M5x16183641,1 8.18 $ (USD)
K0611.02001slitted insidesteel15M6x18204046,4 9.28 $ (USD)
K0611.02201slitted insidesteel15M6x18224248,1 9.79 $ (USD)
K0611.02501slitted insidesteel15M6x18254550,8 10.02 $ (USD)
K0611.02801slitted insidesteel15M6x18284853,7 11.06 $ (USD)
K0611.03001slitted insidesteel15M6x18305458,6 12.67 $ (USD)
K0611.04001slitted insidesteel15M6x18406065 14.62 $ (USD)
K0611.05001slitted insidesteel19M8x25507887 30.94 $ (USD)
K0611.00402slitted insidestainless steel9M3x841620,7 10.27 $ (USD)
K0611.00502slitted insidestainless steel9M3x851620,7 10.27 $ (USD)
K0611.00602slitted insidestainless steel9M3x861620,7 10.27 $ (USD)
K0611.00802slitted insidestainless steel9M3x881822,4 11.10 $ (USD)
K0611.01002slitted insidestainless steel9M3x10102426 14.13 $ (USD)
K0611.01202slitted insidestainless steel11M4x12122831,8 14.61 $ (USD)
K0611.01502slitted insidestainless steel13M5x16153439,4 17.47 $ (USD)
K0611.01602slitted insidestainless steel13M5x16163439,4 17.47 $ (USD)
K0611.01802slitted insidestainless steel13M5x16183641,1 19.97 $ (USD)
K0611.02002slitted insidestainless steel15M6x18204046,4 24.30 $ (USD)
K0611.02202slitted insidestainless steel15M6x18224248,1 25.54 $ (USD)
K0611.02502slitted insidestainless steel15M6x18254550,8 26.91 $ (USD)
K0611.02802slitted insidestainless steel15M6x18284853,7 30.29 $ (USD)
K0611.03002slitted insidestainless steel15M6x18305458,6 31.06 $ (USD)
K0611.04002slitted insidestainless steel15M6x18406065 38.78 $ (USD)
K0611.05002slitted insidestainless steel19M8x25507887 73.14 $ (USD)
K0611.00404slitted insidestainless steel A49M3x841620,7 13.33 $ (USD)
K0611.00504slitted insidestainless steel A49M3x851620,7 13.33 $ (USD)
K0611.00604slitted insidestainless steel A49M3x861620,7 13.33 $ (USD)
K0611.00804slitted insidestainless steel A49M3x881822,4 14.46 $ (USD)
K0611.01004slitted insidestainless steel A49M3x10102426 18.37 $ (USD)
K0611.01204slitted insidestainless steel A411M4x12122831,8 18.99 $ (USD)
K0611.01504slitted insidestainless steel A413M5x16153439,4 22.72 $ (USD)
K0611.01604slitted insidestainless steel A413M5x16163439,4 22.72 $ (USD)
K0611.01804slitted insidestainless steel A413M5x16183641,1 25.94 $ (USD)
K0611.02004slitted insidestainless steel A415M6x18204046,4 29.18 $ (USD)
K0611.02204slitted insidestainless steel A415M6x18224248,1 30.64 $ (USD)
K0611.02504slitted insidestainless steel A415M6x18254550,8 32.29 $ (USD)
K0611.02804slitted insidestainless steel A415M6x18284853,7 36.35 $ (USD)
K0611.03004slitted insidestainless steel A415M6x18305458,6 37.26 $ (USD)
K0611.04004slitted insidestainless steel A415M6x18406065 46.56 $ (USD)
K0611.05004slitted insidestainless steel A419M8x25507887 95.09 $ (USD)
K0611.00403slitted insidealuminum9M3x841620,7 6.72 $ (USD)
K0611.00503slitted insidealuminum9M3x851620,7 6.72 $ (USD)
K0611.00603slitted insidealuminum9M3x861620,7 6.72 $ (USD)
K0611.00803slitted insidealuminum9M3x881822,4 7.17 $ (USD)
K0611.01003slitted insidealuminum9M3x10102426 8.59 $ (USD)
K0611.01203slitted insidealuminum11M4x12122831,8 9.30 $ (USD)
K0611.01503slitted insidealuminum13M5x16153439,4 13.86 $ (USD)
K0611.01603slitted insidealuminum13M5x16163439,4 13.86 $ (USD)
K0611.01803slitted insidealuminum13M5x16183641,1 15.73 $ (USD)
K0611.02003slitted insidealuminum15M6x18204046,4 15.73 $ (USD)
K0611.02203slitted insidealuminum15M6x18224248,1 16.24 $ (USD)
K0611.02503slitted insidealuminum15M6x18254550,8 19.10 $ (USD)
K0611.02803slitted insidealuminum15M6x18284853,7 24.83 $ (USD)
K0611.03003slitted insidealuminum15M6x18305458,6 24.83 $ (USD)
K0611.04003slitted insidealuminum15M6x18406065 32.98 $ (USD)
K0611.05003slitted insidealuminum19M8x25507887 57.82 $ (USD)
