Fixed casters

go back

Products
- Material handling
  - Wheels and rollers
    - Swivel and fixed casters standard version
      - Fixed casters

Item description/product images

DescriptionMaterial:Housing steel plate.
Wheel body PA 6 with vulcanised elastic solid rubber tyre.Version:Pressed housing; wheels with ball bearingNote:Wheel axle bolted.
Wheels are shock and impact proof.Special features:

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet K1762_B Fixed casters

170 kB

Drawings

Item selection/filter

Order No.	Item	Version 1	Wheel bearing	B	B1	B2	B3	D	D1	H	L	L1	Permissible load kg	Price
K1762.100371	Fixed caster	without locking system	roller bearing	32	-	60	85	100	9	125	100	80	170	51.21 $ (USD)
K1762.125371	Fixed caster	without locking system	roller bearing	37	-	60	85	125	9	150	100	80	200	61.87 $ (USD)
K1762.160501	Fixed caster	without locking system	roller bearing	50	75	80	110	160	11	195	140	105	350	106.43 $ (USD)
K1762.200501	Fixed caster	without locking system	roller bearing	50	75	80	110	200	11	235	140	105	400	132.31 $ (USD)
