Item description/product images

DescriptionMaterial:Housing, steel plate.
Wheel rim, high-quality thermoplastic polyurethane.
Wheel tread, high-quality polyamide.Version:Housing press styleed.
Double ball bearing in the castor head.
Plain bearing in wheels.Note:Wheel axle bolted.
Swivel and fixed casters with mounting plate.Application:Loads can be transported with low noise and maximum ease in area's with high hygiene requirements.Temperature range:-20°C to +70°C.Special features:

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet K1775_B Fixed casters for sterile areas

177 kB

Drawings

Item selection/filter

Order No.	Item	Wheel bearing	B	B1	B2	B3	D	D1	H	L	L1	L2	Permissible load kg	Price
K1775.111000351	Fixed caster	plain bearing	35	60	55	85	100	9	125	100	80	76	200	59.36 $ (USD)
K1775.111250401	Fixed caster	plain bearing	40	60	55	85	125	9	150	100	80	76	250	86.53 $ (USD)
K1775.111600451	Fixed caster	plain bearing	45	80	75	110	160	11	195	140	105	-	400	120.08 $ (USD)
K1775.112000501	Fixed caster	plain bearing	50	80	75	110	200	11	235	140	105	-	400	188.24 $ (USD)
