DescriptionMaterial:Steel: case-hardened. Snap ring spring steel. Stainless steel: bright. Snap ring stainless steel.Version:Steel black oxidized. Stainless steel bright.Note:To press onto a thrust point, incline the point as far as possible over the snap ring opening and twist in. The snap ring is supplied assembled.Drawing reference:
style S: standard thrust pad style T: low version, large thrust face
1) thrust face
Special features:
