K0661Horizontal Toggle Clamps with Safety Interlock with straight... |
go back |
|
Item description/product images |
|
|
DescriptionMaterial:Stainless steel.
Grip polyamide.
Unlocking bracket TPE.Version:Bright.
Grip blue, black or red.Note:Maintenance-free high quality link bushings. Sustainable constant force during opening and closing. Optimum stability through the conical, U-profile clamping arm. Includes internal bar lock with automatic safety catch.On request:Other grip colors.Accessory:K0106
K0384
K0390
K0392
K0667Special features: DownloadHere is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table.
|
| Item No. | Component
color | hole
arrangement | Opening
angle of
holding arm | Opening
angle of
handle | Hand
force
FH N | Retaining
force
F1 N | Holding
force
F2 N | Clamping
force
F3 N | Clamping
force
F4 N | CAD | Acc. | Price | Order |
|---|
| K0661.106101 | ultramarine blue RAL 5002 | 3 | 86° | 67° | 160 | 1350 | 1900 | 720 | 1200 |  |  | on request | | | K0661.108101 | ultramarine blue RAL 5002 | 3 | 86° | 67° | 200 | 2000 | 2800 | 830 | 1400 | | | on request | | | K0661.106100 | black gray RAL 7021 | 3 | 86° | 67° | 160 | 1350 | 1900 | 720 | 1200 | | | on request | | | K0661.108100 | black gray RAL 7021 | 3 | 86° | 67° | 200 | 2000 | 2800 | 830 | 1400 | | | on request | | | K0661.106103 | red | 3 | 86° | 67° | 160 | 1350 | 1900 | 720 | 1200 | | | on request | | | K0661.108103 | red | 3 | 86° | 67° | 200 | 2000 | 2800 | 830 | 1400 | | | on request | |
| Item No. | Component
color | M | A
| A1 | A2 | A4 | B | B1 | B2 | B3 | B6 | C | C2 | D | H | H1 | L | L1 | CAD | Acc. | Price | Order |
|---|
| K0661.106101 | ultramarine blue RAL 5002 | M6x35 | 26 | 39 | 6,5 | 2,5 | 14,1 | 9,1 | 17,5 | 12,5 | 53,4 | 36,9 | 8 | 5,5 | 75,2 | 71 | 193,3 | 60,5 | | | on request | | | K0661.108101 | ultramarine blue RAL 5002 | M8x45 | 26 | 44 | 9 | 3,5 | 14,1 | 9,1 | 21 | 16 | 51,1 | 46,5 | 10,5 | 6,2 | 88,2 | 84,3 | 230,4 | 74,9 | | | on request | | | K0661.106100 | black gray RAL 7021 | M6x35 | 26 | 39 | 6,5 | 2,5 | 14,1 | 9,1 | 17,5 | 12,5 | 53,4 | 36,9 | 8 | 5,5 | 75,2 | 71 | 193,3 | 60,5 | | | on request | | | K0661.108100 | black gray RAL 7021 | M8x45 | 26 | 44 | 9 | 3,5 | 14,1 | 9,1 | 21 | 16 | 51,1 | 46,5 | 10,5 | 6,2 | 88,2 | 84,3 | 230,4 | 74,9 | | | on request | | | K0661.106103 | red | M6x35 | 26 | 39 | 6,5 | 2,5 | 14,1 | 9,1 | 17,5 | 12,5 | 53,4 | 36,9 | 8 | 5,5 | 75,2 | 71 | 193,3 | 60,5 | | | on request | | | K0661.108103 | red | M8x45 | 26 | 44 | 9 | 3,5 | 14,1 | 9,1 | 21 | 16 | 51,1 | 46,5 | 10,5 | 6,2 | 88,2 | 84,3 | 230,4 | 74,9 | | | on request | |
